Smart House - Project 240120
Family house in Sofia
Applications Used
Lighting
Heating, Ventilation & Air conditioning (HVAC)
Security and Safety
Operation and Visualisation
Energy Management/Smart Metering
Other
Automation and Remote Access
Blind and Shutter Control
Project Details
| Category | Value |
|---|---|
| Project Category | Family house |
| Project Type | Residential |
| Year of Completion | 2024 |
| Project Size | 501 – 1.000 |
| Number of KNX Devices Used | 26 – 100 |
| KNX Transmission Media | Twisted pair |
| Man Hours | 251 – 500 |
| Man Power | 1 – 5 |
Featured in this project
Detailed Description
Energy Efficiency
The usage of automated functions already save energy in every installation. Especially the usage of KNX has a lot of potential for further energy savings, which can contribute to a better environmental footprint. Be extending KNX to more functions and applications, energy savings of up to 60% can be realised. Thanks to the flexibility of KNX, these functions can easily be implemented in this installation
Innovation
Smart homes and buildings are always an upgrade in comparison to a conventional installation. Not only automated functions and a higher level of comfort contribute to a higher living standard, but also the possibility to be ready for coming innovations. Thanks to the usage of KNX, the door has been opened to integrate new innovative solutions, using the worldwide STANDARD for home and building control.
Applications Used
- Lighting - Switching, Light Scenes, Timed Control
- Heating, Ventilation & Air conditioning (HVAC) - Central & Automatic Control, Individual Room Control / Zone Control, Valve Drive Control / Fan Coil Control, Boiler and burner Control
- Security and Safety - Faults (e.g. Leak Detection, Glass Break Detection, Window Contacts), Access Control, Intrusion Detection / Alarm Systems, Supervision (e.g. Cameras)
- Operation and Visualisation - Switches / Push Buttons, PC Visualisation, Tablets and smart phones
- Energy Management/Smart Metering - Current Detection
- Other - Intercom
- Automation and Remote Access - Logical Functions, System Supervision, Internet Access, Remote Programming
- Blind and Shutter Control - Individual Control, Group & Central Control
Customers Description
This 4-stories single-family house required a complete overhaul of the automation system that was made in 2015 and was severely malfunctioning. The obvious solution to achieve the level of control and comfort the residents requested was to create a completely new KNX installation replacing the old equipment. As a result, 6 distribution boards linked with IP modules are housing all the actuators needed to control a large variety of functions. In addition most of the house is equipped with dry-contact push-buttons, so each signal had to be captured by binary inputs.
Currently, the KNX system control the lighting, the HVAC system (fan coils, radiators, electric heaters, fans, and the summer/winter switchover), the curtains and shutters, the motorized doors and portals, and certain electric circuits such as the pool heating and the water stopping valve controlled by the leakage sensors. There is also an analogue detection of water levels in the rain water draining container.
Contact Information
| Company Name | Valkrea EOOD |
| Company Email | office@valkrea.house |
| Company Website | http://www.valkrea.house |
| Contact Name | Mitko Tsonev |
| Contact Function | System Integrator |
