Education City Future School at Qatar Foundation
Educational in DOHA
Applications Used
Lighting
Heating, Ventilation & Air conditioning (HVAC)
Security and Safety
Operation and Visualisation
Energy Management/Smart Metering
Other
Automation and Remote Access
Blind and Shutter Control
Project Details
| Category | Value |
|---|---|
| Project Category | Educational |
| Project Type | Commercial |
| Year of Completion | 2025 |
| Project Size | 5.000+ |
| Number of KNX Devices Used | 501 – 1.000 |
| KNX Transmission Media | Twisted pair |
| Man Hours | 1.001 – 2.000 |
| Man Power | 11 – 25 |
Featured in this project
Detailed Description
Energy Efficiency
The usage of automated functions already save energy in every installation. Especially the usage of KNX has a lot of potential for further energy savings, which can contribute to a better environmental footprint. Be extending KNX to more functions and applications, energy savings of up to 60% can be realised. Thanks to the flexibility of KNX, these functions can easily be implemented in this installation
Innovation
Smart homes and buildings are always an upgrade in comparison to a conventional installation. Not only automated functions and a higher level of comfort contribute to a higher living standard, but also the possibility to be ready for coming innovations. Thanks to the usage of KNX, the door has been opened to integrate new innovative solutions, using the worldwide STANDARD for home and building control.
Applications Used
- Lighting - Switching, Dimming, Light Scenes, Timed Control, Automatic Occupancy Detection, Constant Light Control, Lighting Colour Control
- Heating, Ventilation & Air conditioning (HVAC)
- Security and Safety - Intrusion Detection / Alarm Systems, Emergency Lighting, Presence Simulation
- Operation and Visualisation - Switches / Push Buttons, PC Visualisation, Web Servers, Touch Panels & Display Panels
- Energy Management/Smart Metering - Data Logging, Visualisation
- Other - Audio Control
- Automation and Remote Access - Timed Functions, Logical Functions, System Supervision
- Blind and Shutter Control
Customers Description
The project consists of 3 buildings with 24 LCS panels, approximately 632 KNX PIR and daylight sensors, 250 multi-gang KNX keypads, 75 dual-channel KNX-DALI gateways (premium version), and 25 multi-channel KNX switching relay modules.
Each building is equipped with DALI-based dimming and switching lighting control systems, KNX PIR and daylight sensor control, and KNX multi-gang keypad control with multiple lighting scene settings and astronomical timing functions. The system also includes photocell control, centralized touchscreen control, and a centralized PC-based graphical NETx lighting control system integrated with the Fire Alarm System, BMS, Audio-Video systems, 4D immersion systems, and DMX interface.
Contact Information
| Company Name | Qatari Computer Systems W.L.L. (Q-Soft) |
| Company Email | santosh@qsoft-corp.com |
| Company Website | https://www.qsoft-corp.com |
| Contact Name | Santosh Sahu |
| Contact Function | System Integrator |
