RC0808 Room Control Unit, 8 Output, 8 Input/2.0

#RCU0808 Room Control Unit
#8x16A Outputs + 8 Digital Inputs
EAE Room Controller Unit is an all-in-one KNX device to control various different room units from a single interface. Room Control Unit provides control of lights, blinds and fan coils as well as optional dry contact inputs.

## General Specifications
Does not require an external power supply

Room Control Unit offers following functions:

- Light switch
- AC/DC blind control
- Fan control
- Fan Coil Control (2 & 3 point valve)
- Dry contact inputs

Switching resistive, capacitive and inductive loads in accordance with EN 60669 with following functions:

- Staircase
- External logic
- Priority
- Threshold
- Operating hour

8 independent input channels with following universal interface functions:

- Switch / push button input
- Dimmer control
- Shutter/blinds control
- Value transfer
- Scene control
- Counter for count pulse

The documents are available at the following link:

`https://www.eaetechnology.com/en/products/knx-products/room-control-uni…`

## Firmware Version
2.x
